External Driver Downlight 8 inch
Wattage: 18W
Max Lumens: 1,480lm
CCT: 2700K|3000K|3500K|4000K|5000K
Features & Benefits
- High efficacy with 8’ light providing upto 1480 lumens
- Operating Temperature: -20°C to +45°C
- Rated for 50,000 hours
- 5-year warranty
Performance Data
| 2700K (90 CRI) | 3000K (90 CRI) | 3500K (90 CRI) | 4000K (90 CRI) | 5000K (90 CRI) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model Number | Wattages | Input Current | Lumens | Efficacy | Lumens | Efficacy | Lumens | Efficacy | Lumens | Efficacy | Lumens | Efficacy |
| HL-DLE-18W-MCCT-8 Inch | 18W | 0.165A | 1,260lm | 70 lm/W | 1,350lm | 75 lm/W | 1,480lm | 82 lm/W | 1,480lm | 82 lm/W | 1,350lm | 75 lm/W |
Product Summary
For Commercial Luminaries, Indoor Lighting, and Offices. Available in Wattage- 18W and has Selectable CCT.
The External Driver Flat Disk is a versatile, low-profile LED round downlight ideal for new construction and drywall ceilings. It clips directly into the ceiling without the need for housing or a ceiling can. Equipped with an external driver, it includes everything needed for installation. Rated for damp locations, it comes with a 5-year warranty.
Applications:
Bathroom, Bedroom, Dining Room, Home Office, Kitchen, and Living Room.
Product Specification
Efficacy
82 lm/W
CCT Options
2700/3000/3500/4000/5000K
CRI
90
Beam Angle
120°
Input Voltage
120 Vac
Power Factor (PF)
>0.9
THD
NA
Dimming
Triac
Operating Temp.
-20°C to +45°C
Warranty
5 Years
Finish
White
Mounting
Recessed
Housing Material
Aluminum Powder Coated
Lens Type
Polystyrene (PS)
FAQ
Frequently Asked Questions (FAQ's)
Is this downlight energy efficient?
Yes, LEDs in this 8-inch unit deliver high lumen output with low wattage, reducing electricity use compared to traditional recessed lights and lowering operating costs.
Are these fixtures suitable for large projects?
Yes, the 8-inch external driver downlight’s efficiency, long life, and selectable CCT make it well-suited for commercial buildings, offices, hospitality, and multi-unit residential projects.
Is installation contractor-friendly?
Yes, the driver box can be mounted above the ceiling, and the light disk clips into the cut-out with spring clips, simplifying installation in new construction or remodel ceilings.
Why choose an external driver downlight?
External drivers improve heat control, lifespan, and ease of maintenance.
Is installation complicated?
No, the driver mounts above the ceiling, and the light fixture snaps into place using spring clips, making installation fast and contractor-friendly.
