Rapid Retro Troffer Door Light 2X4
Wattage: 30W/40W/50W
Max Lumens: 5,236 lm
CCT: 3500K/4000K/5000K
Features & Benefits
- Dimming feature for easy customization
- ETL Certified, DLC Premium, UL listed
- Fully selectable CCT and wattage for customized lighting output
- Delivers up to 5,236lm in the 2×4 variant for high brightness
- Suitable for wet and dry locations
Performance Data
| 3500K (80 CRI) | 4000K (80 CRI) | 5000K (80 CRI) | ||||||
|---|---|---|---|---|---|---|---|---|
| Model Number | Wattages | Input Current | Lumens | Efficacy | Lumens | Efficacy | Lumens | Efficacy |
| HL-2X4-MW-MCCT-50W-Retro Troffer | 30W | 0.46A | 3,549.0lm | 129.9 lm/W | 4,688.2lm | 126.8 lm/W | 5,236.0lm | 121.7 lm/W |
| 40W | 3,567.0lm | 134.0 lm/W | 4,766.0lm | 132.1 lm/W | 5,205.0lm | 127.6 lm/W | ||
| 50W | 3,628.2lm | 132.0 lm/W | 4,733.8lm | 128.7 lm/W | 5,182.0lm | 124.2 lm/W | ||
Product Summary
Available in Selectable CCT & Wattages- 30W/40W/50W
The Havells Troffer Panel Door is a high-performance lighting solution engineered to deliver bright, consistent illumination with a clean, modern aesthetic. Ideal for a wide range of professional environments, it offers adaptable lighting with selectable color temperature and wattage settings. Its slim, integrated design fits seamlessly into ceiling grids, making it a practical choice for contemporary interiors where both efficiency and appearance matter.
Applications:
Commercial Offices, Schools & Educational Facilities, Healthcare Environments, Retail Spaces and Retrofit Projects.
Product Specification
Efficacy
127.6 lm/W
Beam Angle
115°
THD
<20
Warranty
5 Years
Housing Material
CRCA
CCT (Selectable)
3500/4000/5000K
Input Voltage
120–277 Vac
Dimming
0-10V standard
Finish
White
Lens Type
Diffuser
CRI
80
Power Factor (PF)
>0.9
Operating Temp.
-20°C to +40°C
Mounting
Recessed & Surface
FAQ
Frequently Asked Questions (FAQ's)
What is a 2X4 Rapid Retro Troffer Panel Door?
This product is an LED retrofit door assembly designed to upgrade existing 2×4 fluorescent troffer housings. It replaces traditional lamps and doors with an integrated LED light source, improving efficiency, light quality, and reliability without removing the original ceiling fixture.
How easy is installation?
The retrofit panel door is designed to fit compatible existing troffer housings. Contractors can perform upgrades quickly, reducing labor time and minimizing disruption compared to full fixture replacement.
How does selectable wattage help optimize lighting?
Selectable wattage enables adjustment of light output and power consumption during installation. This allows lighting levels to be matched to room size and task needs, improving efficiency and adaptability without replacing the fixture.
